SA516GR70

Steel klas

Chemicla pozisyon %

C Mwens pase oswa egal a

Mn

P Mwens pase oswa egal a

S Mwens pase oswa egal a

sizo

Epesè/mm

Analiz louch

Analiz pwodwi

Analiz louch

Analiz pwodwi

Louch & Pwodwi

Louch

Pwodwi

A516 Gr.55/ SA516 Gr.55

Mwens pase oswa egal a 12.5

0.18

0.60-0.90

0.55-0.98

0.025

0.15-

0.40

0.13-

0.45

>12.5-50

0.20

0.60-1.20

0.55-1.30

>50- 100

0.22

—

A516 Gr.60/ SA516 Gr.60

Mwens pase oswa egal a 12.5b

0.21

—

0.60-0.90

0.55-0.98

>12.5-50

0.23

0.85-1.20

0.79-1.30

>50- 100

0.25

A516 Gr.65/ SA516 Gr.65

Mwens pase oswa egal a 12.5

0.24

0.85-1.20

0.79-1.30

>12.5-50

0.26

>50- 100

0.28

A516 Gr.70/ SA516 Gr.70

Mwens pase oswa egal a 12.5

0.27

0.85-1.20

0.79-1.30

>12.5-50

0.28

—

>50- 100

0.30

—

A515 Gr.60/ SA515 Gr.60

Mwens pase oswa egal a 12.5

0.24

—

Mwens pase oswa egal a 0.90

Mwens pase oswa egal a 0.98

>12.5-50

0.27

—

>50- 100

0.29

A515 Gr.65/ SA515 Gr.65

Mwens pase oswa egal a 12.5

0.28

>12.5-50

0.31

>50- 100

0.33

A515 Gr.70/ SA515 Gr.70

Mwens pase oswa egal a 12.5

0.31

Mwens pase oswa egal a 1.20

Mwens pase oswa egal a 1.30

>12.5-50

0.33

>50- 100

0.35

—

a Pou asye seri A515Gr70, A516Gr70 ak SA516Gr70, lè kontni maksimòm kabòn espesifye a diminye pa 0.01%, valè maksimòm Mn espesifye a gen dwa ogmante pa 0.06%, ak konpozisyon k ap fonn lan kapab. dwe ogmante jiska

1.50%, ak konpozisyon an pwodwi fini ka ogmante jiska 1.60%

B Pou plak asye A516 Klas 60 ak SA516 Klas 60 ak yon epesè mwens pase oswa egal a 12.5mm, konpozisyon fusion Manganèz la ka 0.85-1.20% , ak konpozisyon pwodwi fini a ka 0.79-1.30%.

Pwopriyete mekanik ASME(ASTM) SA516/A516M SA516GR70 (A516GR70)

Steel Klas

tansyon

REDUCTION SIRE/% , Pi gran pase oswa egal a

tansyon

Rm/MPa

Sede Rp0.2/MPa , Pi gran pase oswa egal a

A200mm

A50mm

Epesè / mm

Sede

A516 Gr.60/SA516 Gr.60

415-550

220

21

25

A516 Gr.65/SA516 Gr.65

450-585

240

19

23

A516 Gr.70/SA516 Gr.70

485-620

260

17

21

A515 Gr.60/SA515 Gr.60

415-550

220

21

25

A515 Gr.65/SA515 Gr.65

450-585

240

19

23

A515 Gr.70/SA515 Gr.70

485-620

260

17

21
